S111

S111 Üç Fazlı Çok Fonksiyonlu Akıllı Sayaç

Endüstriyel uygulamalar için güç ve enerji tüketiminin güvenilir, yüksek doğrulukta izlenmesi.

Sağ İşaret

Üç fazlı ve tek fazlı güç ölçümü

Sağ İşaret

Wide voltage range up to 720 VAC

Sağ İşaret

Rogowski bobin akım sensörleri ile yüksek hassasiyet (100A, 1000A, 3000A)

Sağ İşaret

DIN rayına montaj için kompakt tasarım

Sağ İşaret

Tak ve çalıştır RJ12 konnektörleri ile kolay kurulum

Sağ İşaret

Sorunsuz entegrasyon için Modbus/RTU arayüzü

Sağ İşaret

Hassas enerji izleme için gerçek zamanlı ölçüm

The S111 Three-Phase Multi-Functional Smart Meter ensures accurate and reliable power and energy monitoring in industrial environments. Traditional power meters often rely on estimations, but the S111 takes a different approach by measuring voltage and current on all three phases in real time. This results in highly precise readings and more reliable data.

This level of precision allows businesses to monitor and optimize their power consumption more effectively, reducing waste and improving overall energy efficiency.

Seamless Integration

The S111 connects effortlessly to existing industrial networks via Modbus/RTU, ensuring compatibility with a wide range of monitoring and control systems. This ensures compatibility with a wide range of industrial monitoring and control systems, enabling real-time tracking and analysis of power usage.

The device is particularly well-suited for industries that rely on consistent and efficient energy management, such as manufacturing, HVAC, and renewable energy applications.

Compact and Durable Design

Built for easy installation, the S111 fits neatly onto DIN rails in control cabinets, saving space while maintaining robust performance. The inclusion of Rogowski coil technology simplifies the current measurement process, ensuring high accuracy without requiring complex wiring setups. Additionally, the device’s robust construction and IP20 protection class guarantee long-term reliability even in demanding industrial conditions.

Check out the Applications tab to see how the S111 can enhance your industrial power management!

Portable Version for Compressor Efficiency Testing

If you need a mobile setup for compressor efficiency testing, the S110-P Portable Power Meter is the ideal choice. Paired with the S551 Portable Data Logger and the S430 Pitot-Tube Flow Meter, it offers a compact and flexible way to measure power and flow on-site.

Learn more about the S110-P Portable Power Meter and the compressor efficiency testing kit here.

S111 Akıllı Sayaç, birçok sektörde enerji izleme için çok yönlü bir çözümdür:

  • Kompresör İzleme: Kompresör verimliliğini değerlendirmek ve enerji kullanımını optimize etmek için güç tüketimini ölçer. Gerçek zamanlı güç kullanım verileriyle operatörler verimsizlikleri hızla tespit edebilir ve performansı artırmak ve maliyetleri düşürmek için süreçleri ayarlayabilir.
  • Endüstriyel Güç Yönetimi: Maliyetleri azaltmak ve operasyonel verimliliği artırmak için gerçek zamanlı enerji izleme sağlar. İşletmeler, güç tüketimi modellerini analiz ederek, önemli maliyet düşüşlerine ve sürdürülebilirliğin artmasına yol açan hedefli enerji tasarrufu önlemlerini uygulayabilir.
  • HVAC ve Bina Otomasyonu: Isıtma, havalandırma ve iklimlendirme sistemlerinde hassas güç ölçümü sağlar. Bu, enerji israfını en aza indirirken optimum iç mekan iklim koşullarını korumak için çok önemlidir, bu da daha iyi konfor ve daha düşük elektrik giderleri ile sonuçlanır.
  • Yenilenebilir Enerji Sistemleri: Güneş ve rüzgar enerjisi uygulamaları için doğru güç takibi sağlar. S111’in voltaj ve akımı gerçek zamanlı olarak izleme yeteneği, onu yenilenebilir enerji tesislerinde enerji üretimini ve dağıtımını optimize etmek için önemli bir araç haline getirir.
  • Üretim ve Süreç Kontrolü: Tutarlı güç kaynağının korunmasına ve sistem verimsizliklerinin önlenmesine yardımcı olur. Güvenilir güç izleme, üretim süreçlerinin istikrarlı kalmasını sağlayarak maliyetli duruş sürelerini ve üretim kesintilerini önler.

Signal / Interface & Supply

Electrical Data
Power supply18 – 36 VDC, 3.5 VA
Input Signals
Phase voltageL1, L2, L3, N, max 720 VAC
Current sensor3 x Rogowsky coils, integrated type, RJ12
Output Signals
InterfaceModbus/RTU RS 485

General data

Miscellaneous
Protection classIP20
Dimensions95 x 73 x 66 mm
Display1.77” color (TFT screen display)
Weight0.260 kg
Operating conditions
Operating temperature-25°C ... +60°C

Looking for a Portable Version?

The S110-P Portable Power Meter, combined with the S551 Portable Data Logger and the S430 Pitot-Tube Flow Meter, is your go-to solution for on-site compressor efficiency testing. This compact and flexible setup delivers accurate power and flow measurements — wherever you need them.
